How to Repair a Mobile Home Floor.

This article will explain how to repair mobile home floor. Floor repairs are a fairly easy job for a home owner with basic tools to complete.

Floor damage is a common issue caused by  water spills and leaks.

This is  particularly true on some older models that have particle board floors.

Tools that you will need:

  • tape measure
  • torpedo level
  • Safety glasses gloves
  • Chalk line
  • Carpenter’s square
  • Skill saw
  • Pencil
  • Cross cut/miter saw (optional)
  • Drill or driver.
  • Stud finder.

Materials needed.

  • Plywood cut to size
  • 2″ x 4″ studs pt if required.
  • 1 1/2″ to 2 1/4″ deck screws.

Safety First

reapair to a damaged mobile home floor

It goes without saying but I’m going to say it anyway.

Make sure that when you use power tools you’re wearing safety glasses and gloves. Also make sure that the electrical cords to your power tools are in good condition.

Ensure that the area around your job is free of obstacles and obstructions. Allow sufficient space around your job so that your area does not become cluttered and dangerous.

Take your time, the idea here is to save money and not to do the job as fast as a professional.

First Steps Planning Out the Job.

Locate the Sagging or wet area strip back the carpet or the tile locate the floor joists with the stud finder mark off the area affected using the skill saw cut down to the sides of the floor joists remove the the broken wood.

Prepare lengths of 2x4s cut them off to the required length and scab on to the side of the floor joists.

Cut two of the pieces of 2 by 4 to span the distance between the two floor joists. Attach them to the two by fours on the floor joists to make a box-like structure.

How to Make Sure the New Floor Is Flush with the Old.

If you are accurate with your Cuts you can make the box out of the completely and then connect the pieces together and place into the floor.

At this point make sure that the distance between the existing floor and the top of your 2 x 4s is equal to the the thickness of the plywood that you purchased.

Secure the two-by-fours firmly to the floor joists and to each other forming a box section using the inch and a half to two and a quarter inch screws.

Measure and cut the plywood to the correct size using the skill saw the tape measure and the chalk box.

Try Out the Replacement Sub Floor For a Good Fit.

Place the cut piece of plywood into the gap on the floor and make sure that it fits nice and snug. If you have to beat it in there it’s probably too tight it is better to have an eighth of an inch gap.

If the repair is too tight it might cause the floor will swell with the changes in moisture in the home.

What Type Of Nails or Screws to Use.

Using screws will make a better repair and give you the ability to counter sink the screw heads into the plywood

Screw down the plywood making sure you sink the screws just into the plywood. This will ensure that the screws do not show through the top covering of the floor.

Clean Up The Work Area and Put Away your Tools.

Time to clean up and prepare your floor for its new covering.

We hope that you enjoyed this tutorial on How to Repair  Mobile Home Floor.
